EAF2000 Electrical AF4

EAF4 Unit



Carrier Liquids:

Aqueous: any aqueous liquid, pH from 2 - 11, ionic strength from DI water to saline
Organic: THF, MeOH, etc.

Detectors:

UV, RI, laser light scattering, viscometry, fluorescence and more; multiple detectors in-line

System Software:

NovaFFF AF2000 Control
NovaFFF Analysis

Temperature Range:

Room temperature

PC Requirements:

Windows, min. 8 GB RAM, 2 Ethernet-LAN ports, 1 RS232 port



PN2410 Electrical FFF Module

Output / E-Field:

Current: +/- 75 mA*
Max. Voltage: +/- 22.5 V
Resolution: 10 μA
Precision: <1 %
Reproducibility: <0.5 % RSD **

Status Control:

Current read back
Voltage read back
Polarity
Discharge

User Control:

Current
Selection of polarity
Electrode discharge to make sure E-Field is zero

Safety:

Short-circuit proof

Status Indications LED:

Red = field OFF
Green = field active

Environmental Conditions:

Relative humidity 20 – 80 %
(non-condensing) at an operating
temperature range of 10 – 40 °C

Power Requirements:

100 – 240 VAC @ 50 – 60 Hz

Dimensions:

Length x Width x Height
430 x 270 x 90 mm

Weight:

5 kg
